| Dimensions |
6.0 in. H x 2.5 in. W x 3.3 in. D 15.2 cm. H x 6.4 cm. W x 8.5 cm. D
|
| Weight |
5.3 oz./150.0 g
|
| Input Voltage Range |
4.5 to 5.5 VDC host powered; 4.5 to 5.5 VDC external power supply
|
| Operating Current at Nominal Voltage (5.0V) |
175 mA (typical)
|
| Standby Current (idle) at Nominal Voltage (5.0V) |
90 mA (typical)
|
| Color |
Cash Register White, Twilight Black
|
| Supported Host Interfaces |
USB, RS232, Keyboard Wedge, TGCS (IBM) 46XX over RS485
|
| Keyboard Support |
Supports over 90 international keyboards
|
| User Indicators |
Direct decode indicator, good decode LEDs, beeper (adjustable tone/volume)
|
| PERFORMANCE CHARACTERISTICS: |
:
|
| Light Source |
650 nm Laser Diode Class 2
|
| Scan Pattern |
Single line
|
| Scan Speed |
100 scans per second
|
| Scan Angle |
35°
|
| Minimum Print Contrast |
20% minimum reflective difference
|
| Skew Tolerance |
± 10°
|
| Pitch Tolerance |
± 65°
|
| Roll Tolerance |
± 60°
|
| USER ENVIRONMENT: |
:
|
| Operating Temperature |
32° to 122° F/0° to 50° C
|
| Storage Temperature |
-40° to 158° F/-40° to 70° C
|
| Humidity |
5% – 95% RH, non-condensing
|
| Drop Specification |
Designed to withstand multiple drops at 5.0 ft./1.5 m to concrete
|
| Tumble Specification |
Designed to withstand 500 tumbles in 1.64 ft./0.5 m tumbler
|
| Environmental Sealing |
IP30
|
| Electrostatic Discharge (ESD) |
ESD per EN61000-4-2, +/-15 KV Air, +/-8 KV Direct, +/-8 KV Indirect
|
| Ambient Light Immunity |
0 to 8,000 Foot Candles / 0 to 86,080 Lux; tolerant to typical artificial indoor and natural outdoor (direct sunlight) lighting conditions; Fluorescent, Incandescent, Mercury Vapor, Sodium Vapor, LED4: 450 Ft. Candles (4,844 Lux) Sunlight: 8000 Ft. Candles (86,111 Lux)
|
| SYMBOL DECODE CAPABILITY: |
:
|
| Scanning Technology |
Code 39, Code 128, Code 93, Codabar/NW7, Code 11, MSI Plessey, UPC/EAN, I 2 of 5, Korean 3 of 5, GS1 DataBar, Base 32 (Italian Pharma). Refer to Product Reference Guide for complete list of symbologies.
|
| Minimum Element Resolution |
Code 39: 3.0 mil
|
| ACCESSORIES: |
Gooseneck Intellistand
|
| REGULATORY: |
:
|
| Electrical Safety |
EN 60950-1: 2006 + A11: 2009 + A1: 2010 + A12: 2011 + AC 2011; IEC 60950-1: 2005 + A1: 2009; UL 60950-1, second edition; CAN/CSA-C22.2 No. 60950-1-07
|
| EMI/RFI |
FCC 47 CFR Part 15, Subpart B, Class B; ICES-003 Issue 4, Class B; Compliant with EMC Directive 2004/108/EC
|
| Laser Safety |
CDRH Class II, IEC Class 2
|
| Environmental |
Compliant with RoHS irective 2011/65/EU; EN 50581: 2012
|
| UTILITIES AND MANAGEMENT: |
:
|
| 123Scan2 |
Programs scanner parameters, upgrades firmware, provides scanned bar code data and prints reports. For more information, visit http://www.zebra.com/123Scan
|
| Symbol Scanner SDK |
Generates a fully-featured scanner application, including documentation, drivers, test utilities and sample source code. For more information, visit http://www.zebra.com/windowsSDK
|
| Scanner Management Service (SMS) |
Remotely manages your Zebra scanner and queries its asset information. For more information, visit http://www.zebra.com/sms
|
| RECOMMENDED SERVICES: |
Zebra OneCare Select; Zebra OneCare Service Center Select
|
| DECODE RANGES (TYPICAL*) |
:
|
| Symbology/Resolution |
Near/Far
|
| Code 39: 3 mil |
1.6 – 4.8 in./4.1 – 12.2 cm
|
| Code 39: 4 mil |
1.3 – 8.7 in./3.3 – 22.1 cm
|
| Code 39: 5 mil |
0.9 – 11.7 in./2.3 – 29.7 cm
|
| Code 39: 7.5 mil |
0.1 – 19.1 in./0.3 – 48.5 cm
|
| Code 39: 20 mil |
0 – 33.8 in./0 – 85.9 cm
|
| Code 39: 40 mil |
1 – 43.1 in./2.5 – 109.5 cm
|
| UPC: 13 mil (100%) |
0 – 25.1 in./0 – 63.8 cm
|
| * Printing resolution, contrast and ambient light dependent. |
:
|
