BV420T-TS

Categories: , ,

Description

Coming with a new powerful and scalable system architecture the BV420T models are future-proove.  With its ergonomic style and sleek casing these printers suit retail shops, offices or any type of workplace where space is at a premium.  The BV420T thermal transfer printers support a wide range of ribbons from wax to resin.

– Market leading throughput with up to 7 ips

– Compact & sleek design with a small footprint

– Intuitive & clear user experience

– Vast print languages & emulations

– SOTI Connect certified for IoT device management

Specifications

CHARACTERISTICS
Print Method Thermal Transfer, direct thermal
Dimensions (W x D x H) 200 x 267 x 198.3 mm(7.87″ x 10.51″ x 7.81″)
Weight 2.9 kg (6.4 lb)
User Interface 3 LEDs, 2 Keys
Operating Temp./Humidity 5°C to 40°C (41°F to 104°F)
25% to 85% RH (no condensation)
Power Supply AC 100 to 240 V, 50/60 Hz (External AC adapter)
PRINT
Resolution 300 dpi (11.8 dot/mm)
Print Speed (max) 127 mm/sec. (5″/sec)
Print Width (max.) 105.7 mm(4.16”)
Print Length (max.) 997 mm(39.3″)
RIBBON
Width 40 mm to 110 mm(1.57″ to 4.33″)
Length 300 m(984.25′)
MEDIA
Alignment Centred
Media (backing paper) Width 25.4 mm to 118.0 mm(1.00″ to 4.64″)
Label Thickness 0.06 mm to 0.19 mm(0.0024″ to 0.0074″)
Inner Media Core Diameter Standard: 25.4 mm, 38.1 mm, 42 mm(1.0″, 1.5″, 1.65″)
Optional: 76.2 mm(3.0″)
Outer Media Roll Diameter (max.) Standard: Ø127 mm(Ø5.0″)
Optional: Ø214 mm(Ø8.4″)
Media format Roll, fanfold
SOFTWARE & CONNECTIVITY
Emulations ZPL II, DPL, SBPL, EPL2, IPL
Printer Driver Windows 11, Windows 10(32/64 bit), Windows Server 2019/2016/2012 R2/2012, Linux, macOS, SAP
Interface USB 2.0, USB Host, Ethernet 10/100 Base T (IPv4 & IPv6), WLAN 802.11a/b/g/n (dual band for 2.4GHz/5GHz)1)2), Bluetooth V5.2 BR/EDR with MFi certified1)2), Serial port1)
OPTIONS
UHF RFID kit, full cutter module, partial cutter module, peel-off module3), serial interface board, wireless LAN module, Bluetooth module, AC adapter cover, external media stand, print head kits for resolution change

Accessories (Options)

Partial cutter for BV420D
Full cutter for BV420D
External 8” OD Media Stand for BV400D series
RS-232C serial interface for BV400D series
Wi-FI interface (802.11 a/b/g/n) for BV400D series
