DS-2208

Description

2D barcodes have made their way to your Point of Sale, appearing on everything from the items your customers are purchasing to printed and electronic coupons and loyalty cards. Your 1D scanner can’t capture the new 2D codes, leading to exceptions that slow down the check-out process and frustrate customers at that key last personal touchpoint in your store. But with the DS2200 Series, you can scan it all. You get an affordable 1D/2D imager that doesn’t compromise performance or features for price. Your workers get best-in-class first-time, everytime scanning with point-and-shoot simplicity. You get an imager that couldn’t be easier to deploy and manage. And you can choose the model that best fits your POS needs — the corded DS2208 or the cordless DS2278. The DS2200 Series — the affordability your budget demands, with the deployment, ease-of-use and management simplicity your business requires.

Specifications

DS2200 Series Specifications

Physical Characteristics

Dimensions Corded DS2208:
6.5 in. H x 2.6 in. W x 3.9 in. D
16.5 cm H x 6.6 cm W x 9.9 cm D
Presentation Cradle:
2.8 in. H x 3.7 in. W x 4.8 in. D
7.2 cm H x 9.4 cm W x 12.2 cm D
Weight Corded DS2208: 5.7 oz. / 161.6 g
Presentation Cradle: 5.2 oz. / 151 g
Input Voltage Range DS2208 and Cradle: 4.5 to 5.5 VDC Host Powered; 4.5 to 5.5 VDC External Power Supply
Current Corded DS2208 Operating Current at
Nominal Voltage (5.0V):
 250 mA (typical).
(Note: Auto-Aim and Illumination on Acquiring
Image)
Corded DS2208 Standby Current (idle) at
Nominal Voltage (5.0V):
 150 mA (typical).
(Note: Auto-Aim On)
Presentation Cradle and Micro USB Cable:
500 mA (typical) Standard USB; 1100 mA
(typical) BC 1.2 USB
Color Nova White, Twilight Black
Supported Host Interfaces USB, RS232, Keyboard Wedge, TGCS (IBM)
46XX over RS485
Keyboard Support Supports more than 90 international keyboards
User Indicators Direct Decode Indicator; good decode LEDs;
Rear view LEDs; beeper (adjustable tone and
volume)

Performance Characteristics

Motion Tolerance (Handheld) Up to 5 in./13 cm. per second for 13 mil UPC
Swipe Speed (Hands-Free) Up to 30.0 in./76.2 cm. per second for 13 mil UPC
Light Source Aiming Pattern: Linear 624nm Amber LED
Illumination (2) 645nm Super-Red LEDs
Imager Field of View 32.8° H x 24.8° V Nominal
Image Sensor 640 x 480 pixels
Minimum Print Contrast 25% minimum reflective difference
Skew/Pitch/Roll Tolerance +/- 65°; +/- 65°; 0-360°
Minimum Element Resolution Code 39 – 4.0 mil; Code 128 – 4.0 mil;
Data Matrix – 6.0 mil; QR Code – 6.7 mil

User Environment

Operating Temperature DS2208 Imagers:
32.0° to 122.0° F/0.0° to 50.0° C
Presentation Cradle:
32.0° to 104.0° F/0.0° to 40.0° C
Storage Temperature -40.0° to 158.0° F/-40.0° to 70.0° C
Humidity 5% to 95% RH, non-condensing
Drop Specification Designed to withstand multiple drops at 5.0 ft./1.5 m to concrete
Tumble Specification Designed to withstand 250 tumbles in 1.5 ft./.5 m tumbler1
Environmental Sealing IP52
Electrostatic Discharge (ESD) DS2208  Cradle: ESD per EN61000-4-2, +/-15 KV Air, +/-8 KV Direct, +/-8 KV Indirect
Ambient Light Immunity 0 to 10,000 Foot Candles/0 to 107,600 Lux

Radio Specifications

Bluetooth Radio Standard Bluetooth Version 4.0 with BLE:
Direct line of sight in open air: Class 2: Minimum 30 ft. (10.0 m) and up to 300 ft. (100.0 m) when paired with CR2278 cradle. Environmental factors may impact results. Serial Port and HID Profiles; output power adjustable down from 2.0 dBm in 8 Steps

Battery

Battery Capacity/Battery Type 2,400 mAh Li-Ion Battery
Scans Per Battery Charge2 110,000 scans at 60 Scans per Minute or 50,000 scans at 10 Scans per Minute
Operating Time Per Full Charge2 84.0 Hours
Charge Time (from Empty) 14 Hour Shift Hours / Full Charge Hours
Standard USB 14 Hour Shift Hours: 4
Full Charge Hours: 17
BC1.2 USB 14 Hour Shift Hours: 1
Full Charge Hours: 5
External 5V Source 14 Hour Shift Hours: 1
Full Charge Hours: 5
Micro USB 14 Hour Shift Hours: 1
Full Charge Hours: 7
BC1.2 Micro USB 14 Hour Shift Hours: 1
Full Charge Hours: 4

Regulatory

Electrical Safety EN 60950-1 2ed + A11 + A1 + A12 + A2:2013, IEC 60950-1 2ed + A1 + A2, UL 60950-1, CAN/CSA-C22.2 No. 60950-1-07
Environmental RoHS EN 50581
LED Safety IEC 62471
IT Emissions EN 55032 (Class B)
IT Immunity EN 55024
Harmonic Current Emissions EN 61000-3-2
Voltage Fluctuation and Flicker EN 61000-3-3
Radio Frequency Devices 47 CFR Part 15, Subpart B, Class B
Digital Appartus ICES-003 Issue 6, Class B

Cordless Accessories

CR2278 Presentation Cradle, Spare Battery, Micro USB Cable

Decode Capabilities3

Input Voltage Range DS2208: 4.5 to 5.5 VDC
Host Powered; 4.5 to 5.5 VDC External Power Supply
1D Code 39, Code 128, Code 93, Codabar/NW7,
Code 11, MSI Plessey, UPC/EAN, I 2 of 5, Korean 3 of 5, GS1 DataBar, Base 32 (Italian Pharma)
2D PDF417, Composite Codes, TLC-39, Aztec, DataMatrix, MaxiCode, QR Code, Micro QR, Han Xin, Postal Codes
