| Master Making/Printing Methods |
High-speed digital master-making/Fully automatic printing |
| Original type |
Book or sheet |
| Master Making Time*1 |
Quick Master Making Mode |
Approx. 18 seconds
(A4, short-edge feed) |
| Normal Master Making Mode |
– Approx. 16 seconds
(A4, long-edge feed)
– Approx. 20 seconds
(A4, short-edge feed) |
| Resolution |
Scanning |
600 dpi × 600 dpi |
| Printing |
300 dpi × 600 dpi,
Quick Master Making mode: 300 dpi × 400 dpi |
| Maximum Scanning Area |
297 mm × 432 mm |
| Print paper weight |
46 gsm to 210 gsm |
| Print Paper Size*2 |
100 mm × 148 mm to 310 mm × 432 mm |
| Maximum Printing Area |
291 mm × 413 mm |
| Paper Feed Tray Stacking Capacity |
1000 sheets*3, stacking height of 110 mm or lower |
| Paper Receiving Tray Stacking Capacity |
1000 sheets*3, stacking height of 110 mm or lower |
| Print Speed |
6 levels: 60, 80, 100, 120, 130, and 150 (High Speed*4) ppm |
| Print Position Adjustment |
Horizontal: ±15 mm, Vertical: ±10 mm |
| Image Processing Mode |
Line, Photo (Standard/Portrait),
Duo (Standard/Line/Photo/Shadow off),
Pencil (Darker/Lighter) |
| Print Reproduction Ratio |
Zoom (50% to 200%), Free, 100% reproduction ratio, Margin+ (90% to 99%), 4 levels
of enlargement (163%, 141%, 122%, 116%), 4 levels of reduction (87%, 82%, 71%, 61%) |
| User Interface |
Color touch panel |
| Functions |
Image, Contrast, Size, Paper Size Detection, Dot Process, Contrast Adj., Tone Curve, Multi-Up Print, Book Shadow, Top Margin Adj., Binding Margin Adj., Max. Scan, Ink Saving, Quick Master Making, Preview, ADF Semi-Auto*5, Storage, Overlay, Print Speed Adj., Print Density Adj., Print Position Adj., Interval, Renew Page, Auto Page Renewal, Rotate, Special Paper Ctrl, Program, Slip Sheet Sorting, Job Separation*6, Job Memory, Reservation, Idling Action, Confidential, My Direct Access, Meter Display, ID Counter Report, Proof Copy, Direct Printing, USB Job List, Paper Memory Print, Scanning Mode, Admin., Auto Sleep, Auto Power-OFF, Power-OFF Schedule, ECO Mode, Protect, RISO iQuality System |
| PC Interface |
USB2.0, Ethernet:100BASE-TX, 10BASE-T |
| Ink Supply |
Full automatic (1000 ml/cartridge) |
| Master Supply/Disposal |
Full automatic
(A3: approx. 220 sheets per roll) / Disposal capacity:
approx. 100 sheets |
Full automatic
(B4: approx. 250 sheets per roll) / Disposal capacity:
approx. 100 sheets |
Full automatic
(Legal: approx. 250 sheets per roll) / Disposal capacity:
approx. 100 sheets |
| Power Source |
AC 100-240 V, 50-60 Hz <3.4-1.6 A> |
| Power Consumption |
Standard |
Max.: 300 W, Ready: 20 W or lower, Sleep: 5 W or lower, Power-OFF: 0.5 W or lower |
| Optional Accessories Connected *7 |
Max.: 315 W, Ready: 30 W or lower, Sleep: 10 W or lower, Power-OFF: 0.5 W or lower |
| Dimensions(W×D×H) |
In use |
1415 mm × 670 mm*8 × 1065 mm*9 |
| In storage |
780 mm × 670 mm*8 × 1065 mm*9 |
| Required Space (W×D×H) |
1415 mm × 1240 mm × 1515 mm*9 |
| Weight |
102 kg*10 |
